10: Kubernetes Scheduler: Understanding How It Works with Examples

The Kubernetes Scheduler is a critical component of the Kubernetes control plane. It is responsible for determining which node in the cluster will run a newly created pod. Let’s explore how the Kubernetes scheduler works, its two-step process, and the different ways to influence scheduling decisions. Examples are provided for clarity.

---

How Does the Kubernetes Scheduler Work?

The scheduler operates in the following sequence when scheduling pods:

1. Request Flow:

   • A user or controller issues a request (e.g., using kubectl) to the API server.

   • The API server modifies the state in etcd, marking the pod's status as Pending.

1. Scheduler's Role:

   • The scheduler identifies any pods with the Pending status and takes responsibility for assigning them to a node.

2. Binding:

   • Once the best node is identified, the pod is bound to it, changing the pod's state from Pending to Running.

1. Two-Step Scheduling Process: The scheduler follows two steps to assign the best node:

   • Filtering Nodes: Eliminates nodes that do not meet the pod’s requirements (e.g., resource requests, hardware specifications, or taints).

   • Ranking Nodes: Scores the remaining nodes based on resources and policies, selecting the most suitable node.

---

Example of Scheduling

Scenario:

We have a cluster with seven nodes (A to G). Only nodes B, D, and G have GPUs.

Steps:

1. Filtering:

   • Nodes A, C, E, and F are removed because they lack GPUs.

   • Remaining nodes: B, D, G.

2. Ranking:

   • Node B: GPU utilization = 50%.

   • Node D: GPU utilization = 100%.

   • Node G: GPU utilization = 0%.

   • The scheduler selects Node G because it has the most available resources (100% GPU free).

3. Binding:

   • The pod is bound to Node G, changing its status to Running.

If no node satisfies the requirements, Kubernetes can choose a node randomly or based on additional rules.

---

Can We Influence Scheduling Decisions?

Yes! Kubernetes provides several ways to influence the scheduler’s behavior:

1. Node Name:

You can specify a particular node for a pod using the nodeName field in the pod specification.

Example:

spec:
  nodeName: node-1

When you describe the pod, the events will show that no scheduling occurred because the pod was directly assigned to a specific node.

---

2. Node Selector:

A Node Selector lets you bind pods to nodes with specific labels. This is a simple one-condition matching mechanism.

Steps:

1. Label nodes with specific attributes (e.g., cpu=i7 or disk=ssd):

    kubectl label nodes node-1 disk=ssd


2. Use the label in your pod definition:

    spec:
      nodeSelector:
        disk: ssd


Mistakes:

• If you apply the wrong label, you can fix it using --overwrite:

    kubectl label nodes node-1 disk=hdd --overwrite


Difference Between -l and -L:

• -l: Filters resources by label.

• -L: Lists the values of specific labels.

---

3. Node Affinity and Anti-Affinity:

Node Affinity supports multi-condition matching with logical operators (AND/OR), providing more flexibility than Node Selectors.

• Node Affinity: Assigns pods to specific nodes based on labels and conditions.

• Node Anti-Affinity: Avoids assigning pods to nodes with certain labels.

Example:

affinity:
  nodeAffinity:
    requiredDuringSchedulingIgnoredDuringExecution:
      nodeSelectorTerms:
      - matchExpressions:
        - key: disk
          operator: In
          values:
          - ssd

In this example, the pod will only be scheduled on nodes with the label disk=ssd.

---

4. Pod Affinity and Anti-Affinity:

• Pod Affinity: Ensures pods are scheduled on the same node as other pods with matching labels.

• Pod Anti-Affinity: Prevents pods from being scheduled on the same node as pods with matching labels.

Example:

affinity:
  podAffinity:
    requiredDuringSchedulingIgnoredDuringExecution:
      labelSelector:
        matchLabels:
          env: dev
      topologyKey: "kubernetes.io/hostname"

Here, pods with env=dev labels will be placed on the same node.

---

5. Taints and Tolerations:

• Taints: Used to repel pods from a node.

• Tolerations: Allow pods to tolerate a node’s taint.

Example of Taint:

kubectl taint nodes node-1 key=value:NoSchedule

Example of Toleration:

tolerations:
- key: "key"
  operator: "Equal"
  value: "value"
  effect: "NoSchedule"

---

Conclusion

The Kubernetes scheduler is a powerful tool that ensures optimal placement of pods across nodes. By understanding and using features like nodeName, Node Selectors, Affinities, and Taints, you can have fine-grained control over where your pods run. Whether you want to co-locate pods for efficiency or separate them for redundancy, Kubernetes provides the flexibility to meet your needs.
