9: Kubernetes: Using LimitRange and Network Policies with Examples

Kubernetes offers robust features to manage resources and secure communication between pods and namespaces. In this blog, we’ll explore two such features: LimitRange and Network Policies, with detailed explanations and practical examples to help you implement them in your cluster.

---

1. Managing Resource Quotas with LimitRange

What is LimitRange?

A LimitRange is a Kubernetes object used to enforce constraints on resource requests and limits for pods or containers within a namespace. It ensures resources are allocated fairly and avoids scenarios where a single application consumes excessive resources, causing instability in the cluster.

Why Use LimitRange?

• Prevent Over-Allocation: Avoid resource contention by setting maximum limits.

• Stability: Ensure a minimum allocation of resources to avoid application crashes.

How LimitRange Works

When a LimitRange is applied to a namespace:

1. Pods or containers must request resources within the defined min and max boundaries.

2. If resource requests are not specified in a pod's definition, Kubernetes applies the default values from the LimitRange.

---

Example: Applying LimitRange

Here’s an example YAML file for a LimitRange:

apiVersion: v1
kind: LimitRange
metadata:
  name: example-limitrange
  namespace: test
spec:
  limits:
  - default:
      cpu: "500m"
      memory: "512Mi"
    defaultRequest:
      cpu: "200m"
      memory: "256Mi"
    max:
      cpu: "1"
      memory: "1Gi"
    min:
      cpu: "100m"
      memory: "128Mi"
    type: Container

This configuration sets the following constraints:

• Minimum: Pods must request at least 100m CPU and 128Mi memory.

• Maximum: Pods cannot request more than 1 CPU and 1Gi memory.

• Defaults: If no values are specified, Kubernetes assigns 500m CPU and 512Mi memory.

Apply the LimitRange

Save the YAML file as limit-range.yaml and apply it to the test namespace:

kubectl apply -f limit-range.yaml

---

Scenario: What Happens Without Resource Requests?

Without a LimitRange, attempting to create a pod without specifying resource requests or limits may cause the pod to fail or consume unbounded resources. With a LimitRange, the pod inherits the default values, ensuring it runs within the constraints.

Check Pod Resource Allocation

You can verify the pod’s resource allocation with the following command:

kubectl describe pod <pod-name>

Look for the QoS Class, which should show Burstable, indicating the pod uses the default values.

---

2. Securing Communication with Network Policies

What is a Network Policy?

A Network Policy is a Kubernetes resource that controls the flow of traffic between pods, namespaces, and external endpoints. By default, all pods in Kubernetes can communicate with each other. Network Policies allow you to enforce restrictions based on your application’s security requirements.

For more details, refer to the Kubernetes Network Policies documentation.

---

Example: Applying Network Policies

Step 1: Create a Namespace and Label It

Let’s start by creating a namespace test and labeling it for identification:

kubectl create ns test
kubectl label ns test area=test
kubectl get ns --show-labels

---

Step 2: Define a Network Policy

Below is an example Network Policy that allows all pods in the prod namespace to receive ingress (incoming) traffic from any source:

apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: allow-all-ingress
  namespace: prod
spec:
  podSelector: {}
  policyTypes:
  - Ingress
  ingress:
  - from:
    - podSelector: {}

Explanation:

• podSelector: {}: Matches all pods in the prod namespace.

• policyTypes: Ingress: The policy applies to incoming traffic.

• from with podSelector: {}: Allows traffic from all pods in any namespace.

---

Step 3: Apply the Network Policy

Save this YAML as network-policy.yaml and apply it:

kubectl apply -f network-policy.yaml

---

Step 4: Verify the Network Policy

List the applied network policies in the prod namespace:

kubectl get networkpolicy -n prod

---

Advanced Use Case: Namespace-to-Namespace Communication

Suppose you want to allow a pod in the test namespace to communicate with a pod in the prod namespace. The following Network Policy achieves this:

apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: allow-test-to-prod
  namespace: prod
spec:
  podSelector:
    matchLabels:
      role: backend
  policyTypes:
  - Ingress
  ingress:
  - from:
    - namespaceSelector:
        matchLabels:
          area: test
      podSelector:
        matchLabels:
          role: frontend

Explanation:

• Namespace Selector: Only allows traffic from namespaces labeled with area=test.

• Pod Selector: Only allows traffic from pods labeled role=frontend in the test namespace to pods labeled role=backend in the prod namespace.

---

Conclusion

• LimitRange: Helps enforce resource allocation constraints, ensuring stability and preventing resource overuse or application crashes.

• Network Policies: Enhance security by controlling pod communication within and across namespaces.

By implementing these features, you can optimize resource usage and enforce strong security policies in your Kubernetes cluster. Try these configurations in your environment to see their impact in action!
